Imaging and Optical Data

IR Resolution: 320 × 240

MSX Resolution: 320 × 240

Thermal Sensitivity: <0.06°C

Detector: Uncooled Microbolometer

Screen 3.0 in. 320 × 240 color LCD

Image Modes: IR image, visual image, MSX, picture-in-picture

Multi Spectral Dynamic Imaging (MSX): IR image with enhanced detail presentation

Temperature Range –4° F to 482°F (–20° to 250°C)

Alarm Blue below or red above set temperature

Emissivity Correction Variable from 0.1 to 1.0
